S Series 1.5-2.0 Ton Three Wheel Electric Forklift
The Sinolift CPDS Three Wheels AC Electric Forklift is designed for efficient and safe operation in narrow spaces, wet or uneven surfaces, and busy warehouses. Its high-visibility German steel mast, fully hydrostatic power steering, and heavy-duty AC motors ensure precise maneuvering and reliable performance. The intelligent multi-functional LCD dashboard provides real-time operational information, while the strong unibody frame and maintenance-free wet disc brakes offer durability and low upkeep. Ideal for indoor logistics, storage, and stacking tasks, this forklift combines efficiency, safety, and operator comfort for demanding material handling environments.
Features
Sinolift CPDS Three Wheels AC Electric Forklift Truck
– Efficiency, reliability and safety, easy to maintenance and service.
– High visibility masts constructed of German steel.
– Heavy duty and highly efficient motors.
– The new multi-functioinal LCD dash board provides more information for operator.
– Fully hydrostatic power steering and tilt steering wheel.
– Strong unibody construction.
Parameters
| Characteristics | Manufactuer | SINOLIFT FORKLIFT | |||||
| Model | CPDS15 | CPDS18 | |||||
| Rated capacity | kg | 1500 | 1750 | ||||
| Load center | mm | 500 | |||||
| Power type | Battery | ||||||
| Tyres | Super elastic | ||||||
| No. of tyres (front/rear) | 2/2 | ||||||
| Dimensions | Lift height B | mm | 3000 | 3000 | |||
| Free lift height E | mm | 130 | 130 | ||||
| Fork size NxUxL | mm | 35×100×920 | 35×120×920 | ||||
| Upright tilt(forward/backward) K/T | deg | 5/7 | |||||
| Overall dimensions | Length to fork face | mm | 2780 | 2830 | |||
| Length to fork face(without fork) J | mm | 1860 | 1910 | ||||
| Wheel width | mm | 1050 | |||||
| Overall width W | mm | 1070 | |||||
| Height with mast lowered C | mm | 1980 | |||||
| Height withmast extended A | mm | 3945 | |||||
| Height of overhead guard D | mm | 1990 | |||||
| Turning radius(outside) P | mm | 1500 | |||||
| Front overhang G | mm | 360 | |||||
| Right-angle store aisle (pallet 800×1200,1000×1200) RASA | mm | 2860/3060 | 2910/3110 | ||||
| Performance | Travel speed(with/without load) | km/h | 13.2/14.3 | 12.8/14 | |||
| Lifting speed(with/without load) | mm/sec | 300/470 | |||||
| Lowering speed(with load) | mm/sec | 450 | |||||
| Max. pulling force | KN | 14.84 | 13.08 | ||||
| Grade ability(with load) | % | 20 | 19 | ||||
| Weight | Service mass(including battery) | kg | 3100 | 3260 | |||
| Load per axle | Full load (front/rear) | kg | 4020/560 | 4300/640 | |||
| Without load (front/rear) | kg | 1540/1540 | 1480/1740 | ||||
| Chassis | Tyres size | Front | 18×7-8 PR | ||||
| Rear | 16×6-8 PR | ||||||
| Wheel base F | mm | 1295 | |||||
| Wheel tread | Front Q | mm | 895 | ||||
| Rear S | mm | 205 | |||||
| Ground clearance | Mast H | mm | 80/85 | 75/85 | |||
| (full load/without load) | Frame M | mm | 100/110 | ||||
| Service brake | Hydraulic | ||||||
| Power unit | Battery | Type | Ironclad plates | ||||
| Voltage/capacity | V/Ah | 48/505 | |||||
| Mass | kg | 850 | |||||
| Electric motor | Traction, power | kw | 6.5×2 | ||||
| Lift,power | kw | 12 | |||||
Product Details
Fully hydrostatic power steering
Fully hydrostatic power steering for excellent maneuverability. Imported multifunctional liquid crystal instrument with intelligent display for fault codes, battery status, and forklift running information.
Control system
Three-fulcrum electric forklift truck with imported drive axle and imported full AC control system.
Three speed modes
Three running modes to choose from according to different needs: low speed, moderate speed, and high speed.
Wet butterfly brake
Maintenance-free wet disk brake: unlike traditional drum brakes, besides changing the oil, the system does not require extensive regular maintenance, reducing maintenance costs.
FAQ
Q1: Why choose a three-wheel electric forklift for warehouse operations?
A1: A three-wheel electric forklift is designed for superior maneuverability, making it ideal for narrow aisles and confined warehouse spaces. Its compact turning radius allows operators to move, turn, and stack goods more efficiently than many traditional forklifts, improving productivity in warehouses and logistics centers.Q2: Do you need a license to operate a three-wheel electric forklift?
A2: In most countries and regions, operators are required to receive professional training and obtain a valid forklift operator certification before operating an electric forklift. Even though the forklift is designed with ergonomic controls and smooth steering, proper training is still recommended to ensure safe and efficient operation.Q3: Is the three-wheel electric forklift suitable for wet or uneven ground conditions?
A3: Yes, the forklift is designed to maintain stable performance even when working on slightly wet or uneven surfaces. Its balanced structure and responsive steering system help operators maintain better control and stability during operation.Q4: How does the forklift improve operator safety and visibility?
A4: The forklift features a high-visibility mast design that allows operators to clearly see the load and surrounding working area. Panoramic rearview mirrors and an intelligent LCD display also provide better operational awareness, helping reduce blind spots and improve safety.Q5: What makes this electric forklift easy to maintain for daily operation?
Q5: What makes this electric forklift easy to maintain for daily operation? A5: The forklift is designed with maintenance efficiency in mind, including durable AC motors and service-friendly components. The side-pull battery design allows faster battery replacement and easier maintenance access, helping reduce downtime in daily operations.
Optional Extras
Cabin with Heater
Stay productive through the cold seasons. The optional heated cabin provides a warm, comfortable environment for operators, ensuring safety and efficiency are maintained even in freezing outdoor conditions.
Cabin with Air Conditioner
Conquer the heat without losing momentum. The air-conditioned cabin option delivers a cool, controlled workspace that reduces operator fatigue and maintains peak performance during hot weather operations.
Special Forks
Optimize your material handling with our range of specialized forks. These attachments are designed to safely and efficiently handle unique loads, such as coils, drums, or blocks, enhancing both productivity and application versatility.
Weigher System
Keep track of load weight instantly and accurately with the integrated weighing system. This feature enhances operational safety and efficiency by preventing overloads and streamlining material handling workflows.
Spark Arrestor
Operate with confidence in sensitive environments. The spark arrestor effectively contains hot particles, significantly reducing fire risk when working near combustible materials or in dry, high-risk areas.
Blue spot light
The blue spot light projects a visible beam on the ground, indicating the forklift’s direction of travel. This enhances safety by alerting nearby workers to the forklift’s movements, especially in busy environments.
Alarm Lamp
With an alarm lamp integrated into the design, this device offers a highly visible warning solution for forklifts and industrial vehicles. The bright, flashing light enhances safety by alerting personnel to the presence of the vehicle, especially in busy or low-visibility environments. Available in various colors, including amber, red, and blue, the alarm lamp can be customized to meet different safety requirements and regulations. Durable and weather-resistant, it ensures reliable performance in diverse working conditions, helping to prevent accidents and improve overall workplace safety.
Reverse Alarm
The reverse alarm adds an important safety feature by emitting a loud sound when the stacker is moving in reverse. This alerts nearby personnel of the stacker’s movement, reducing the risk of collisions or accidents. The reverse alarm is especially useful in crowded environments, helping to keep both operators and others in the workspace aware of the stacker’s actions.
Mirror
Equipped with a mirror, this option improves rear visibility for the operator, enhancing safety when maneuvering in tight or crowded spaces.
Cold store protection
Designed for extreme cold storage environments, this electric pallet truck is equipped with specialized features such as cold store oil, anti-slip platforms, and heated batteries. Built to operate seamlessly in low-temperature conditions, it ensures reliable performance and durability in harsh environments. With enhanced insulation and robust components, this version guarantees efficiency and safety in demanding cold storage applications.
Fire Extinguisher
This quick-release, vehicle-mounted fire extinguisher is specifically designed for forklifts, featuring OSHA-compliant construction for industrial safety. Its easy-access mounting and instant activation ensure rapid response to engine, battery or electrical fires. The compact yet powerful system provides reliable protection for operators and equipment in critical situations. Vibration-resistant brackets keep the unit securely in place during all forklift operations.
