EPT20K-Li EPT25K-Li EPT30K-Li
EPT20K-Li EPT25K-Li EPT30K-Li Pedestrian Electric Pallet Truck
The SINOLIFT EPT20K-Li lithium-ion electric pallet truck combines compact agility with robust 2000kg capacity, ideal for navigating narrow aisles, docks, and ramps. Its industry-leading turning radius and 24V lithium battery ensure zero maintenance, fast charging, and all-shift productivity. Featuring an AC drive motor, regenerative braking, and ergonomic tiller with emergency reverse, it delivers effortless operation in warehouses, cold stores, and confined spaces.
Features
Parameters
| Manufacturer | SINOLIFT | ||
| Model | EPT20K-Li | ||
| Power Type | LEP | ||
| Type of Operation | Pedestrian | ||
| Load capacity/Rated load | q | kg | 2000 |
| Load Center Distance | c | mm | 600 |
| Alex centre to Fork Face | x | mm | 948 |
| Wheelbase | y | mm | 1265 |
| Total Weight (with battery) | kg | 335 | |
| Axle Load(laden):Drive side/Load-bearing side | kg | ||
| Axle Load(unladen):Drive Side/Load-bearing side | kg | ||
| Tyre Type | Polyurethane | ||
| Tyre Size ( Load Wheel) | mm | φ80×60 | |
| Tyre Size (Drive Wheel) | mm | φ210×70 | |
| Tyre Size (Caster Wheel) | mm | φ230×75 | |
| Wheels Quantity, front/rear (x=Driving Wheels) | 4/1x+2 | ||
| Track Width,Front,Driving Side | b10 | mm | 520 |
| Track Width,Rear,Loading Side | b11 | mm | 400 |
| Lifting Height | h3 | mm | 190 |
| Height of Tiller Arm in Driving Position, Min.- Max. | h14 | mm | 950-1250 |
| Lowered Height | h13 | mm | 85 |
| Overall Length | l1 | mm | 1620 |
| Length to Fork Face | l2 | mm | 460 |
| Overall Width | b1 | mm | 680 |
| Fork Dimension | s/e/l | mm | 54x160x1150(1220) |
| Fork Spread Width | b5 | mm | 560/680 |
| Ground Clearance at Center of Wheelbase (Min) | m2 | mm | 27 |
| Aisle Width for Pallets 1000×1200 Crossways | Ast | mm | 2415 |
| Aisle Width for Pallets 800×1200 Crossways | Ast | mm | 2315 |
| Turning Radius | Wa | mm | 1430 |
| Traveling Speed (Laden/Unladen) | km/h | 2.5/3 | |
| Lifting Speed (Laden/Unladen) | mm/s | 35/45 | |
| Lowering Speed (Laden/Unladen) | mm/s | 50/40 | |
| Max.Gradient Performance (Laden/Unladen) | % | 5/8 | |
| Service Brake Type | Electromagnetic | ||
| Driving Motor Rating (DC) S2 60min | kw | 0.75 | |
| Lifting Motor Rating S3 15% | kw | 0.8 | |
| Battery Type | Li-ion | ||
| Battery Voltage/Capacity K5 | V/Ah | 48/30 (size:120*220*340mm) | |
| Battery Weight | kg | 50 | |
| Charger | V/A | Oct-48 | |
| Controller Model | DC | ||
| Steering Type | Mechanical | ||
| Sound level atdriver’s ear according to EN 12 053 | dB | 70 | |
Product Details
Upgraded Multi-Function Manual Handle
• Ergonomic Design: Can be operated comfortably with both hands. • Anti-Collision Self-Stop: Automatically stops upon impact for safety. • Smooth Movement: Roller turns effortlessly for easy operation.
Reinforced Fork StructureReinforced Fork Structure
• Thickened Fork: Integral stamping for enhanced durability. • High Load-Bearing Capacity: Thickened steel construction ensures stability and prevents rollover. • Reinforced Fork Tip: Thickened design resists deformation; durable paint resists fading.
Efficient Lifting System
• Smooth Hydraulic/Electric Lifting: Saves time and effort. • Intelligent Electric Design: Streamlines loading/unloading, significantly improving work efficiency.
Superior Terrain Performance
Strong Ridge & Slope Climbing: Handles 5% gradients when fully loaded, 7% when unloaded.
FAQ
-
What is the battery life of the EPT20K-Li pallet truck, and how long does it take to charge?
The 24V lithium battery provides 8-10 hours of continuous operation on a full charge, with a fast charging time of just 2-3 hours. Unlike lead-acid batteries, it supports opportunity charging without memory effect. -
Can this electric pallet truck handle slopes or uneven surfaces?
Yes! It climbs 5% slopes when loaded and 7% when empty, with high ground clearance and polyurethane tires for stability on docks, ramps, and rough floors. -
How does the lithium battery reduce maintenance compared to lead-acid?
The lithium battery is completely maintenance-free—no watering, acid leaks, or periodic discharge needed. It also lasts 3x longer than traditional batteries. -
Is the EPT20K-Li suitable for cold storage environments?
Absolutely! An optional cold store configuration ensures reliable operation in temperatures as low as -20°C (-4°F) without performance loss.
Optional Extras

Li-on Battery (Lithium Phosphate Battery)
Opt for the Lithium Phosphate Battery (LiFePO₄) to power your electric pallet truck. This advanced battery technology delivers high safety, long cycle life, and stable performance, making it ideal for demanding operations. With fast charging, minimal maintenance, and eco-friendly benefits, it’s a perfect upgrade for multi-shift applications in modern warehouses and logistics.

Load backrests
When goods are stacked high, the load backrest can prevent it from falling, ensuring user and items safety. To protect the operator from falling objects, electric pallet trucks and stackers have an overhead guard. Electric Pallet Truck with load Backrest for using the boxes and taller loads to be moved safely and easily.

With scale (printer
Electric pallet truck equipped with an integrated scale and printer allows operators to weigh loads while moving them and print labels on the spot. Perfect for logistics and warehousing, it enhances efficiency and accuracy in inventory management.

Cold store version
Designed for extreme cold storage environments, this electric pallet truck is equipped with specialized features such as cold store oil, anti-slip platforms, and heated batteries. Built to operate seamlessly in freezing conditions, it ensures reliable performance and durability in harsh environments. With enhanced insulation and robust components, this version guarantees efficiency and safety in demanding cold storage applications.

Smart Charger for Electric Pallet Trucks
This intelligent charger automatically optimizes voltage and current with multi-stage charging technology to maximize battery performance and lifespan. Featuring advanced protection systems, it delivers fast, safe, and efficient charging tailored for industrial applications. The smart charging management reduces downtime while maintaining optimal battery health. An ideal solution to keep your electric pallet trucks operating at peak efficiency.

Wheels
PU wheels
Polyurethane wheels have a lower rolling resistance, making them easier to pull compared to nylon wheels. They are ideal for use on soft floor types like laminated and polished tile, as they are long-lasting and durable.
Nylon wheels
Nylon wheels, on the other hand, are better suited for harsh and debris-filled environments. They are tougher, more durable and less likely to suffer damage than polyurethane wheels when used in cold storage, wet, or rough floors.

Customized Fork Solutions
This electric pallet truck offers fully customizable fork options, including lengths, widths, extensions, and carriages, tailored to meet specific operational needs. Whether handling heavy loads, oversized items, or unique shapes, these features ensure optimal performance, safety, and efficiency. Additionally, customized stall shelves maximize storage space and improve organization, streamlining your operations for versatile material handling in any workspace.

pin-code handle
The key pad access handle integrates a digital keypad into the handle, requiring a unique PIN to operate the truck. This ensures only authorized personnel can access the equipment, adding a layer of security against unauthorized use. Ideal for warehouses, manufacturing facilities, or shared settings, it prevents theft, misuse, and errors. Combined with Personal PIN-CODE settings, it offers a secure yet user-friendly access control solution for authorized operators.
