  5. 1.5ton 2 ton Narrow aisle CQD15B 20B Electric Reach stand Forklift Truck

EPT20-15ET2

EPT20-15ET2 High Quality Assembly Electric Pallet Truck

The EPT20-15ET2 Electric Pallet Truck is designed for efficient and effortless material handling in narrow spaces, combining power, durability, and compactness. With a 1.5-ton capacity and a high-quality assembly, it outperforms manual pallet trucks in lifting, lowering, and transporting goods. Its semi-enclosed, elegant design and modular construction ensure easy maintenance, while the compact body enhances agility in tight pathways. Ideal for warehouses, factories, and logistics centers, it features an ergonomic tiller, energy-saving 85AH battery, and upgraded safety components like an emergency switch and optimized wiring. A revolutionary choice for eco-friendly and cost-effective operations.

Features

Watch the EPT20-15ET2 in Action – Your Efficient Warehouse Partner!

This video demonstrates how our 1.5-ton electric pallet truck combines power, compact design, and smart features to streamline your material handling. Key highlights:

Strong & Stable – High-quality assembly ensures durability for daily operations.

Space-Saving – Compact size maneuvers easily in narrow aisles.

Easy Maintenance – Modular design and 85AH battery for hassle-free use.

Safety First – Emergency switch, BDI indicator, and optimized wiring.

Parameters

ModelEPT20-15ET2
Rated load(kg)1500
Load center B11(mm)600
Operation typeWalking style
Standard fork width b5(mm)560(685)
Fork length(mm)1150
Fork thickness(mm)50
Fork width(mm)150
Overall length(mm)1638
Minimum turning radius(mm)1485
Minimum channel width(1000x1200mm,Tray)(mm)1739
Minimum channel width(800x1200mm,Tray)(mm)1939
Maximum running speed, full load / no load(km/h)4/4.5
Maximum lifting speed, full load / no load(m/s)0.029/0.038
Maximum down speed, full load / no load(m/s)0.046/0.033
Dead weight with battery(kg)195
Tire materialPolyurethane
Running power(kw)0.65
Lifting power(kw)0.84
Voltage / capacity(V/Ah)24/65
Running brakingElectromagnetic brake
BrakeBattery brake



Product Details

Media Gallery

FAQ

  • How long does the battery last, and what type is it?

    This pallet truck uses an 85AH rechargeable battery, providing long runtime for continuous operation. The upper-installed charger improves heat dissipation, enhancing charging efficiency. For optimal performance, regular charging after use is recommended.
  • Can the EPT20-15ET2 operate in narrow warehouse aisles?

    Yes! Its compact design allows easy maneuverability in tight spaces, making it perfect for narrow warehouse aisles. The small body size ensures smooth movement without compromising lifting power. This makes it a great choice for crowded storage environments.
  • Is maintenance difficult for the EPT20-15ET2?

    No, it features a modular design for easy disassembly and maintenance. The detachable battery cover simplifies replacements, and the durable construction reduces wear and tear. Minimal upkeep is needed, making it a cost-efficient long-term solution.
  • What safety features does this electric pallet truck have?

    It includes an emergency stop switch, ergonomic tiller with safety controls, and a protective cover for the drive wheel. The optimized wiring reduces failure risks, while the battery indicator (BDI) ensures power monitoring. These features enhance operator safety in busy workplaces.

Optional Extras

Li-on Battery (Lithium Phosphate Battery)

Opt for the Lithium Phosphate Battery (LiFePO₄) to power your electric pallet truck. This advanced battery technology delivers high safety, long cycle life, and stable performance, making it ideal for demanding operations. With fast charging, minimal maintenance, and eco-friendly benefits, it’s a perfect upgrade for multi-shift applications in modern warehouses and logistics.

Load backrests

When goods are stacked high, the load backrest can prevent it from falling, ensuring user and items safety. To protect the operator from falling objects, electric pallet trucks and stackers have an overhead guard. Electric Pallet Truck with load Backrest for using the boxes and taller loads to be moved safely and easily.

With scale (printer

Electric pallet truck equipped with an integrated scale and printer allows operators to weigh loads while moving them and print labels on the spot. Perfect for logistics and warehousing, it enhances efficiency and accuracy in inventory management.

Cold store version

Designed for extreme cold storage environments, this electric pallet truck is equipped with specialized features such as cold store oil, anti-slip platforms, and heated batteries. Built to operate seamlessly in freezing conditions, it ensures reliable performance and durability in harsh environments. With enhanced insulation and robust components, this version guarantees efficiency and safety in demanding cold storage applications.

Smart Charger for Electric Pallet Trucks

This intelligent charger automatically optimizes voltage and current with multi-stage charging technology to maximize battery performance and lifespan. Featuring advanced protection systems, it delivers fast, safe, and efficient charging tailored for industrial applications. The smart charging management reduces downtime while maintaining optimal battery health. An ideal solution to keep your electric pallet trucks operating at peak efficiency.

Wheels

PU wheels

Polyurethane wheels have a lower rolling resistance, making them easier to pull compared to nylon wheels. They are ideal for use on soft floor types like laminated and polished tile, as they are long-lasting and durable.

Nylon wheels

Nylon wheels, on the other hand, are better suited for harsh and debris-filled environments. They are tougher, more durable and less likely to suffer damage than polyurethane wheels when used in cold storage, wet, or rough floors.

Customized Fork Solutions
This electric pallet truck offers fully customizable fork options, including lengths, widths, extensions, and carriages, tailored to meet specific operational needs. Whether handling heavy loads, oversized items, or unique shapes, these features ensure optimal performance, safety, and efficiency. Additionally, customized stall shelves maximize storage space and improve organization, streamlining your operations for versatile material handling in any workspace.

pin-code handle

The key pad access handle integrates a digital keypad into the handle, requiring a unique PIN to operate the truck. This ensures only authorized personnel can access the equipment, adding a layer of security against unauthorized use. Ideal for warehouses, manufacturing facilities, or shared settings, it prevents theft, misuse, and errors. Combined with Personal PIN-CODE settings, it offers a secure yet user-friendly access control solution for authorized operators.
