Sinolift China NF series stainless steel galvanized type hydraulic hand pallet truck



The NF Hand Pallet Truck is a versatile and durable solution designed for transporting goods on pallets up to 3,000kg, ideal for warehouses, logistics, and industrial environments. Featuring a parking brake for enhanced safety, ergonomic tiller design for fatigue-free operation, and a neutral control system for smooth handling, it ensures efficient and safe material movement. With high-quality PU tires, overload prevention, and descending speed control, it protects both goods and floors while offering quiet, high-durability performance. Its robust hydraulic system, durable construction, and large steering angle make it suitable for heavy-duty applications, ensuring reliability and ease of use in demanding settings.

Liên hệ với chúng tôi
Tải về

Đặc trưng

The High-Performance Hand Pallet Truck is designed for heavy-duty material handling, featuring non-marking, abrasion-resistant PU or poly nylon wheels for smooth and floor-friendly operation. Its robust body, heavy-duty frame, and sturdy tow bar ensure exceptional durability, while the high-quality hydraulic pump with a die-casted one-piece body guarantees reliable lifting and lowering control. The ergonomic 3-stage lever handle (lift, neutral, release) and additional paddle release point make operation effortless and precise. With a 210° turning radius and high-quality PU steering wheels, this pallet truck offers superior maneuverability, making it ideal for warehouses, construction sites, and industrial environments. The powered-coated finish and heavy-duty steel construction further enhance its longevity and performance.

Các tham số

Người mẫu Dung tích Chiều rộng nĩa Chiều dài phuộc Chiều cao tối thiểu Chiều cao tối đa Bánh lái Bánh xe tải Cân nặng
kg/lbs mm/inch mm/inch mm/inch mm/inch (mm) (mm) kg/lbs
W1 L1 H2 H1 A B
NF15-48 1500/3300 460/18″ 810/32″ 80/3.15″ 200/7.9″ φ180*50 φ78*100 (single) 66/145
NF15-49 460/18″ 980/38.5″ 70/154
NF15-58 520/20.5″ 810/32″ 66/145
NF15-59 520/20.5″ 980/38.5″ 70/154
NF15-510 520/20.5″ 1070/42″ 71/156
NF15-511 520/20.5″ 1150/43.3″ 73/160
NF15-610 600/23.5″ 1070/42″ 77/169
NF15-76 685/48″ 650/25.6″ 68/149
NF15-710 685/27″ 1070/42″ 76/167
NF15-712 685/27″ 1220/48″ 79/173
NF25-58 2500/5500 520/20.5″ 810/32″ 80/3.15″ 200/7.9″ φ180*50 φ78100 (single) or φ7870 (tandem) 67/147
NF25-59 685/27″ 980/38.5″ 71/156
NF25-510 685/27″ 1070/42″ 72/158
NF25-511 520/20.5″ 1150/43.3″ 75/165
NF25-712 685/27″ 1220/48″ 80/176
NF30-510 3000/6600 520/20.5″ 1070/42″ 80/3.15″ 200/7.9″ φ180*50 φ78100 (single) or φ7870 (tandem) 84/184
NF30-511 520/20.5″ 1150/43.3″ 90/198
NF30-712 685/27″ 1220/48″ 100/220
Bản vẽ kết cấu

Bản vẽ kết cấu

Bản vẽ kết cấu

Bản vẽ kết cấu

Chi tiết sản phẩm

fork does

Thickening steel

Bottom reinforcing unit to increase the strength and durability of the body

welded oil pump，the oil cylinder is equipped with manual relief value

Thư viện phương tiện truyền thông

Câu hỏi thường gặp

  • What is the difference between Polyurethane and Nylon wheels?

    Polyurethane is generally the most popular wheel type and is a cast wheel with a polyurethane tyre around the outside, this wheel gives better grip on smooth floors and is quieter than nylon. This softer wheel type also tends to be better for use on sensitive floors Nylon wheels are a hard rigid plastic wheel, they tend to be better in areas where there may be debris on the floor such as engineering workshops etc as the debris will not penetrate into the wheel.

  • Can you supply a certificate of conformity?

    Yes, but this must be requested at the time of order and an administration charge may apply.

  • What is die-cast one-piece design, and what are its advantages in hydraulic pump body manufacturing?

    Die-casting is a manufacturing process where molten metal is injected into a mold under high pressure to create precise and complex shapes. The die-cast one-piece design is used for hydraulic pump bodies to produce strong, durable, and leak-proof components with high dimensional accuracy. This design eliminates joints and seams, reducing the risk of leaks and improving structural integrity. It enhances durability, simplifies maintenance, and ensures consistent performance under heavy loads, making it ideal for heavy-duty applications.

  • What's Your Warranty For The Material Handling Equipment？

    Chúng tôi cung cấp bảo hành một năm, bảo hành này sẽ bao gồm các lỗi không phải do sử dụng sai như quá tải hoặc đặt nhầm sản phẩm. Và không bảo hành các bộ phận bị mòn như bánh xe và cầu chì.

Các tùy chọn bổ sung

Nylon

Nylon
Choose nylon pallet truck steer wheels for low rolling resistance, long life, and cost-effectiveness. Ideal for smooth surfaces and light to medium-duty applications.

Polyurethane
Choose polyurethane treaded pallet truck steer wheels for quiet operation, excellent grip, and resistance to wear. Suitable for indoor use on smooth or slightly uneven surfaces.

Steel
Choose steel steer wheels for durability in harsh working environments, such as metalworking areas or heavy-duty industrial settings. They are resistant to impact and can handle heavy loads.

Cao su
Choose solid rubber treaded steer wheels for quiet operation and smooth rolling over uneven or rough surfaces. They provide excellent shock absorption and are ideal for environments where floor protection is a priority.

Tiller

Choose a tiller that suits your habits and preferences

zinc or hot-galvanized type

The galvanized hand pallet truck is designed with a protective zinc coating, providing exceptional resistance to corrosion. It is an ideal choice for wet or humid environments, ensuring durability and reliable performance in challenging conditions.

Stainless steeltype

The stainless steel hand pallet truck is crafted from high-quality stainless steel, offering superior corrosion resistance and hygiene. Perfect for environments requiring strict cleanliness standards, such as food processing or pharmaceutical industries, it combines strength with easy maintenance.

equipped with scale

This handy tool combines a manual pallet truck with a built-in weighing scale, letting you move and weigh loads at the same time. Perfect for warehouses or logistics, it saves time and boosts efficiency by handling and measuring in one go.

Heavy duty type

For even heavier demands, this upgraded pallet truck offers a 5-tonne capacity and a reinforced 8mm steel frame, making it stronger and more robust than standard models. Designed for demanding environments like warehouses and logistics, it handles heavier loads with ease while ensuring durability and safety. Perfect for industrial-grade challenges!

load bracket

It’s an essential accessory designed to secure and stabilize loads during transport. It ensures safe and efficient handling of goods, making it ideal for moving irregular or unstable items with ease.
