NAV50 Heavy Duty Design Hand Pallet Jack

Sinolift China NAV50 heavy duty design hand pallet jack or truck with thickened steel easy handling/high-quality oil pump

This heavy-duty pallet truck, with a 5-tonne capacity and reinforced 8mm steel frame, is designed for demanding industrial environments such as warehouses, manufacturing, and logistics. Featuring an ergonomic handle, reliable hydraulic system, and customizable brake options, it ensures durability, operator comfort, and safety, making it ideal for heavy-load handling tasks.

Bize Ulaşın
İndirmek

Özellikler

Parametreler

Örnek NAV50-510 NAV50-712 NAV50-715 NAV50-718 NAV50-720
Yük Kapasitesi kilogram 5000 5000 5000 5000 5000
Yük Kapasitesi mm 500 500 600 600 600
Direksiyon mm Φ180*65 Φ180*65 Φ180*65 Φ180*65 Φ180*65
Yük Tekerleği mm Φ78*70 Φ78*70 Φ78*70 Φ78*70 Φ78*70
Max.Çatal Yüksekliği mm 200 200 200 200 200
Min.Çatal Yüksekliği mm 85 85 85 85 85
Genel Uzunluk mm 1534 1604 1884 2184 2384
Çatal Boyutu mm 54/165/1070 54/165/1200 54/165/1500 54/165/1800 54/165/2000
Çatallar üzerindeki genişlik mm 540 685 685 685 685
Dönüş yarıçapı mm 1249 1319 1609 1919 2029
Self Weight kilogram 110 123 148 159 167
Yapısal çizimler
Yapısal çizimler

Ürün Detayları

Heavy duty design, 5 tonne capacity, 8mm reinforced steel frame ensures rugged durability and long lasting performance.

Perfect for all kinds of manual handling tasks

One-piece cast pump，reliable oil-tight hydraulic system

Thickened and reinforced steel spring provides excellent rebound for years of service.

Medya Galerisi

SSS

  • What is a Manual Pallet Truck?

    A manual pallet truck, commonly referred to as a manual pallet jack, pallet truck, or hand pallet truck, is a material handling tool designed for transporting palletized loads within a warehouse or similar settings. It serves as a simple and cost-effective solution for lifting and moving pallets.

  • How Does a Manual Pallet Truck Work?

    A manual pallet truck features a steel frame equipped with a pair of forks that can be inserted beneath a pallet. The forks are operated hydraulically and can be raised or lowered using a pump handle located on the truck’s handle. By pumping the handle, the hydraulic system lifts the forks, elevating the pallet off the ground. The operator can then maneuver the pallet truck by pushing or pulling it to the desired location. To lower the forks and release the pallet, the operator simply releases the hydraulic pressure by operating a release lever.

İsteğe bağlı ekstralar

Nylon

Nylon
Choose nylon pallet truck steer wheels for low rolling resistance, long life, and cost-effectiveness. Ideal for smooth surfaces and light to medium-duty applications.

Poliüretan
Choose polyurethane treaded pallet truck steer wheels for quiet operation, excellent grip, and resistance to wear. Suitable for indoor use on smooth or slightly uneven surfaces.

Steel
Choose steel steer wheels for durability in harsh working environments, such as metalworking areas or heavy-duty industrial settings. They are resistant to impact and can handle heavy loads.

Lastik
Choose solid rubber treaded steer wheels for quiet operation and smooth rolling over uneven or rough surfaces. They provide excellent shock absorption and are ideal for environments where floor protection is a priority.

Tiller

Choose a tiller that suits your habits and preferences

zinc or hot-galvanized type

The galvanized hand pallet truck is designed with a protective zinc coating, providing exceptional resistance to corrosion. It is an ideal choice for wet or humid environments, ensuring durability and reliable performance in challenging conditions.

Paslanmaz çeliktype

The stainless steel hand pallet truck is crafted from high-quality stainless steel, offering superior corrosion resistance and hygiene. Perfect for environments requiring strict cleanliness standards, such as food processing or pharmaceutical industries, it combines strength with easy maintenance.

equipped with scale

This handy tool combines a manual pallet truck with a built-in weighing scale, letting you move and weigh loads at the same time. Perfect for warehouses or logistics, it saves time and boosts efficiency by handling and measuring in one go.

Heavy duty type

For even heavier demands, this upgraded pallet truck offers a 5-tonne capacity and a reinforced 8mm steel frame, making it stronger and more robust than standard models. Designed for demanding environments like warehouses and logistics, it handles heavier loads with ease while ensuring durability and safety. Perfect for industrial-grade challenges!

load bracket

It’s an essential accessory designed to secure and stabilize loads during transport. It ensures safe and efficient handling of goods, making it ideal for moving irregular or unstable items with ease.
