Sinolift China High Quality Cpd08m Cpd10m Cpd12m Mini Electric Forklift Truck
Sinolift China High Quality Cpd08m Cpd10m Cpd12m Mini Electric Forklift Truck - Image 2
Sinolift China High Quality Cpd08m Cpd10m Cpd12m Mini Electric Forklift Truck - Image 3
Sinolift China High Quality Cpd08m Cpd10m Cpd12m Mini Electric Forklift Truck - Image 4

Sinolift China High Quality Cpd08m Cpd10m Cpd12m Mini Electric Forklift Truck

The CPD08M, CPD10M, and CPD12M mini electric forklift trucks are designed for businesses seeking efficient, eco-friendly, and space-saving material handling solutions. Their compact size and advanced features make them ideal for indoor warehouses, retail environments, and other constrained spaces where maneuverability and precision are essential. The versatile CPD-M mini forklift performs tasks as reliably as comparable diesel or LPG forklifts, excelling in both indoor and outdoor applications. It proves its value in industries requiring high availability, such as logistics, mechanical engineering, automotive, chemical and plastics, and food retail. Thanks to its compact dimensions and optimized steering geometry, the truck is extremely maneuverable, making it perfect for use in confined spaces.

Contact Us
Download

Features

The vehicle has a compact appearance and a small turning radius, which can work in narrow passages or floors

Lightweight, convenient energy-saving, flexible control mechanism, reliable and safe

Using battery as power source, pure power, no pollution, meeting national environmental protection needs

Using permanent magnet synchronous control system, stable control, accurate, energy-saving and high-efficiency

The main electrical components are all well-known brand products, with stable performance and reliable quality

According to the principle of ergonomics, the driver’s operating space is reasonably allocated, and the operation is comfortable and convenient

The whole vehicle covering parts are made of one-piece forming stamping parts, which are beautiful, strong and durable

Parameters

Manufacturer SINOLIFT
Model CPD08M CPD10M CPD12M CPD16M
Power Type Electric
Type of operation Seated
Load capacity/rated load Q kg 800 1000 1200 1 600
Load center distance C mm 400  400
Loaddistance, center of drive axle to fork L2 mm 314  354
Wheelbase L1 mm 1150 1250
Mast/fork carriage tilt forward/backward a/B 5/8 5/8
Mast lowered height H1 mm 1990 2020
Free lift height H3 mm / /
Standard mast lifting height H mm 3000 3000
Extended mast height H2 mm 4090 4075
Overhead load guard height H4 mm 2000 2100
Seat height mm 920 1020
Coupling height mm 300 320
Overall length (with fork) L mm 2580 2800
Overall length (without fork) L” mm 1810 2030
Overall width W1 mm 990 990
Fork dimension TxWxL4 mm 30x100x770 30x100x770
Type of fork carriage ISO23282A ISO2328 2A
Fork carriage width mm 1060 1060
Fork carriage spread width W5 mm 970 970
Ground clearance under mast laden H5 mm 100 130
Ground clearance from center of wheelbase H6 mm 130 140
Min. Right Angle Stacking Aisle Width  (pallet size 1000×1000) Ast mm 3264 3454
Min. Right Angle Stacking Aisle Width (pallet size 1200×1200) Ast mm 3064 3254
Turning radius r mm 1550 1700
Weight (with battery) kg 1585 1645 2010 2070
Front axle rated load (laden) kg 2225 2480 3010 3460
Rear axle rated load (laden) kg 160 165 200 210
Front axle rated load (unladen) kg 665 690 845 870
Rear axle rated load (unladen) kg 920 955 1165 1200
Tyre type Solid tyre Solid tyre
Front tyre size 459×157 21x7x15
Rear tyre size 15×4.5-8/3.00D-8 5.00-8-8PR/3.00D-8
Tyre quantity (x=driving wheels) 2x/2 2x/2
Front-wheel span mm 915 930
Rear-wheel span mm 815 810
Travel speed (laden/unladen) km/h 12/13 12/13
Lift speed (laden/unladen) mm/s 192/200 200/217
Lowering speed (laden/unladen) mm/s 400/294 370/265
Max. Gradeability (Laden/Unladen) % 12/15 12/15
Service brake Hydraulic Hydraulic
Parking brake Mechanical Mechanical
Drive motor rating S260min kW 3.7kw  permanent magnet synchronous motor 5.5kw permanent magnet synchronous motor
Lift motor rating at S315% kW 3.7kw permanent magnet synchronous motor 5.5kw permanent magnet synchronous motor
Battery voltage/normal capacity K5 V/Ah 60V/120AH 60V/150AH 60V/180AH 60V/200AH
Battery weight kg 195 195 345 345
Maximum allowable battery size mm / / / /
Drive controller manufacture TIANFU TIANFU TIANFU TIANFU
Type of drive controller TFCB60400-CAN TFCB60400-CAN TFCB60500-CAN TFCB60500-CAN
Operating pressure for attachments bar 74 92 110 147
Oil volume for attachments L/min / / / /
Hydraulicoil tank volume L 18.3 18.3 18.3 18.3
Sound level at driver’s ear according to EN 12 053 dB 70 70 70 70

Exceptional Stability and Efficient Design
Traction motors are arranged in parallel, batteries are fixed at the bottom of the truck frame, and the wheelbase and rear-wheel distance have been extended to enhance the swing point of the steering axle and shorten the front overhang distance, ensuring excellent stability. Streamlined appearance design with flexible and smooth lines, compact and powerful truck shape, achieving optimal energy efficiency.

High-Quality Components and Safety Certification
Motor controllers, connectors, power plugs, emergency switches, dashboards, and accelerators are all from world-renowned brands, ensuring reliable performance and easy maintenance. Emergency switches comply with European safety regulations, with overload protection for electronic and hydraulic systems. The entire truck meets CE certification standards.

Ergonomic Operator Experience
Ergonomically designed operator cabin with a longer wheelbase providing more legroom. The steering wheel diameter is reduced to 300mm, and seats can be adjusted forward and backward for optimal driving positions. Humanized features such as storage space and USB interfaces are added for enhanced convenience.

Fully Hydrostatic Power Steering and Superior Maneuverability
Equipped with a small-diameter steering wheel and fully hydrostatic power steering mechanism, offering low turning force and quick response, significantly improving maneuverability and reducing operator fatigue. Standard steering knob synchronizer function, ideal for narrow aisles and tight corners.

Diverse Battery Options and Smart Features
A variety of DIN battery options (600Ah, 630Ah, 700Ah, 775Ah, depending on wheelbase) are available. A battery discharge indicator (BDI) and lift interrupt function are standard on all trucks. Environmentally friendly design, lightweight, and low maintenance costs, suitable for various applications such as warehouses, docks, and retail stores.

Structural Drawings

Structural Drawings

Structural Drawings

Product Details

CPD08M CPD10M CPD12M CPD16M 04

Large capacity battery work continuously for 5-6 hours

CPD08M-CPD10M-CPD12M-CPD16M 05

HD LCD display with automatic diagnosis function can self-diagnose operation errors,system failures

CPD08M-CPD10M-CPD12M-CPD16M 06

Adjustable seat

Handbrake button

Handbrake button

Media Gallery

FAQ

  • What is the load capacity of a mini electric forklift truck?

    Mini electric forklifts typically handle loads ranging from 500kg to 2000kg, depending on the model. Always check the specific model's specifications to ensure it meets your requirements.

  • How long does the battery last on a full charge?

    The battery life varies by model but generally lasts 6-8 hours of continuous operation. Advanced models may offer quick-charging capabilities and replaceable battery packs for extended use.

  • Can mini electric forklifts be used outdoors?

    While primarily designed for indoor use, some models with durable tires and weather-resistant features can operate on smooth outdoor surfaces. They may not be suitable for rough terrain or heavy rain.

  • What maintenance does a mini electric forklift require?

    Maintenance is minimal compared to traditional forklifts. Key tasks include: Regularly checking and charging the battery. Inspecting tires, brakes, and lifting mechanisms. Keeping electrical components clean and free of debris.

  • Is a license required to operate a mini electric forklift?

    Yes, most countries require operators to have forklift certification or training, even for smaller models. This ensures safe operation and compliance with workplace safety regulations.

Optional Extras

Lithium-ion Battery

Lithium-ion batteries are a game-changer in material handling equipment, offering high energy density, lightweight design, and fast charging capabilities. Compared to traditional lead-acid batteries, they provide up to 30% more efficiency, longer lifespan, and require minimal maintenance. Ideal for multi-shift operations, they support fast charging without the need for battery swaps, reducing downtime. With superior performance, compact size, and eco-friendly benefits, lithium-ion batteries are the perfect choice for modern warehouses and logistics, ensuring productivity and cost savings.

Cold store protection

Designed for extreme cold storage environments, this electric pallet truck is equipped with specialized features such as cold store oil, anti-slip platforms, and heated batteries. Built to operate seamlessly in low-temperature conditions, it ensures reliable performance and durability in harsh environments. With enhanced insulation and robust components, this version guarantees efficiency and safety in demanding cold storage applications.

Sideway battery extraction

Designed for multi-shift operations, the high-capacity battery features a sideway extraction system on rollers, enabling quick and effortless battery changes. This ensures minimal downtime and maximizes productivity in demanding work environments.

Blue spot light

The blue spot light projects a visible beam on the ground, indicating the forklift’s direction of travel. This enhances safety by alerting nearby workers to the forklift’s movements, especially in busy environments.

Non-marking tyre
Non-marking tyres are designed to leave no traces on sensitive flooring, making them ideal for use in clean environments like food processing plants or retail spaces. They offer excellent traction and durability without compromising floor integrity.

Front Dual Tyre
The front dual tyre configuration enhances stability and weight distribution, allowing the forklift to carry heavier loads with improved balance. This option is ideal for environments that require handling large or heavy items, providing better traction and reducing the risk of tipping.

SE Tyre
SE tyres are designed for durability and performance on rough surfaces, making them suitable for heavy-duty operations in rugged environments. They improve the forklift’s stability and extend the lifespan of the tyres, ensuring reliable performance over extended periods of use.
