QSD30 QSD60

Sinolift QSD30 QSD60 Rider-Seated Electric Tow Tractor

The Sinolift QSD30/QSD60 rider-seated electric tow tractor combines advanced German engineering with a rugged, user-friendly design, making it ideal for towing heavy loads and industrial equipment in distribution centers, factories, and warehouses. Its compact and versatile build ensures excellent maneuverability, while the energy-efficient, virtually noise-free operation enhances productivity. Featuring ergonomic controls, a low center of gravity, and superior stability, this battery-powered tractor effortlessly transports materials with precision and reliability, perfect for demanding industrial environments.

Contact Us
Download

Features

  • Wheelbase provides a tight turning radius for maximum maneuverability and control in confined work environments.
  • Rear Bridge Drive Unit provides excellent power and gradeability.
  • Ergonomically Designed Compartment allows easy operation of all controls and pedals to help reduce operator fatigue.
  • Forward/Reverse Lever and a floor- mounted accelerator pedal provides fast and easy direction control changes.
  • Heavy duty suspension seat with arms, multi-angle back support, sliding
  • base and safety belt, which improve overall operator comfort and safety.
  • Low Step Height allows for easy entry and exit.
  • Small-Diameter Steering.

Parameters

Identification 1.1 Manufacture’s type designation SINOLIFT
1.2 Model QSD30 QSD60
1.3 Power Type                         Electric
1.4 Type of operation                         Seated
1.5 Steering Mode               Electric Power Steering
1.6 Wheelbase.   y mm 1110 1110
Weight 2.1 Total Weight(with battery) kg 985 1180
2.2 Axde Loadunladen:Drive: sde/ad-bearigside kg / /
Dimension 3.1 Overall length 1 mm 2030 2030
3.2 Overall width   W1 mm 1020 1020
3.3 Overall height h5 mm 1350 1350
3.4 Coupling Height(Hook center above ground) h1 mm 300/350/400 300/350/400
3.5 Seat height h2 mm 965 965
3.6 Ground Clearance at the center of wheelbase(Min) m1 mm 110 110
3.7 Turning Radius Wa mm 1520 1520
Tyre 4.1   TyreType Inflatable rubber wheel Inflatable rubber wheel
4.2 Tyre Size(Front) 4.00-8 4.00-8
4.3 Tyre Size(Rear) 4.00-8 4.00-8
4.4 Wheels Quantity, front/rear (x=drving wheels) 1X/2 1X/2
Performance 5.1 Traveling Speed(aden/unladen) Km/h 7.5/15 7.5/15
5.2 Rated Draw-bar Pull F N 3800 4500
5.3 MaxGradient Performance S25min (laden/unladen) %   6/15 6/15
5.4 Service Brake Type Hydraulic Hydraulic
5.5 Parking BrakeType Mechanical Mechanical
Power Unit 6.1 Drive Motor Rating(AC)S2-60min kW 5 5
6.2 Battery Voltage/Capacity K5 V/Ah 48/200 48/350
6.3 Battery Weight kg 360 545
Others 7.1 Controller Brand CURTIS CURTIS
7.2 Controller Model 1232SE 1232SE
7.3 Sound level at driver’s ear according to EN 12 053 dB 70 70

Structural Drawings

Structural Drawings

Product Details

The tractor adopts the same electronic power steering as the wheel of the car

48V/350AH/LEOCH high capacity deep cycle lead acid battery,working life up to 6 hours

Ergonomic comfort seat

Ride on electronic throttle

Media Gallery

FAQ

  • What is the maximum towing capacity of a rider-seated electric tow tractor?

    The towing capacity typically ranges from 3,000 kg to 6,000 kg, depending on the model and manufacturer. Always check the specifications for the specific application requirements.

  • How long does the battery last, and what is the charging time?

    Battery life can vary based on usage and load but generally lasts 6hours of continuous operation. Charging times usually range from 1.5 hours, depending on the battery type (e.g., lead-acid or lithium-ion).

  • What safety features are included in rider-seated electric tow tractors?

    Common safety features include: Emergency stop buttons Anti-roll-back systems on inclines Speed control mechanisms LED warning lights and horns Ergonomic seat designs with seat belts

  • Can it operate on uneven or sloped surfaces?

    Most rider-seated electric tow tractors are designed for smooth, flat surfaces. However, some models are equipped to handle slopes up to 10-15% gradient, depending on the load and tire design.

  • What types of industries commonly use rider-seated electric tow tractors?

    These tow tractors are widely used in: Warehousing and logistics for moving carts and trailers Manufacturing plants for assembly line towing Airports for luggage handling Retail distribution centers for moving goods Hospitals for transporting heavy equipment or medical supplies

Optional Extras

Versatile Cabins: Stand-up Tow Tuggers offer flexible cabin customization options such as semi-closed, fully enclosed, with a heater or air conditioner, and more, catering to diverse applications.

Cutting-edge Lithium Battery: These tuggers are powered by a robust lithium battery that boasts superior longevity and charging speed, surpassing traditional lead-acid batteries.

Precise Inching Switch: The inclusion of an inching switch allows the operator to carry out slow and precise movements, crucial for navigating tight spaces with ease.

Effortless Battery Removal: The side roll-out feature of the battery in Stand-up Tow Tuggers facilitates uncomplicated maintenance and replacement procedures

Enhanced Visibility: A reflecting mirror supplements the operator’s view, providing clarity and promoting safety when maneuvering.

Safety First: With an alarm lamp integrated into the design, Stand-up Tow Tuggers prioritize safety, making sure everyone in the area is aware of its presence.
